Browse to specify where to save the file.Specify a prefix or suffix to add to the file name.Provide a file name to avoid name duplication issues.

Stitch (IGES and STEP files only) stitches several edge-matched surfaces or faces together.

Individual imports the assembly as individual surface features in the part environment.

Composite imports the assembly as a single composite feature in the part environment.

Each composite feature has its own browser node that is a child of the root node. Each level, layer, or group is created as an individual composite feature that has the same name as the level, layer, or group it originates from.

Composite PartThe composites are created from the levels, layer, or groups.

Multi-body part imports an assembly as solid bodies in a single part.

Assembly preserves the source structure.

#HOW TO OPEN A DWG FILE IN AUTODESK INVENTOR HOW TO#

Specify how to import solids into the file: The following options are only available if Convert Model is selected as the Import Type. To edit the import options after importing, right-click on the file in the browser, and select Edit Import from the context menu.

Select the file to import and click Open.

In the applicable dialog box, set the Files of type to view the available files.

To import into an assembly, select Assemble tab Component panel Place Imported CAD.

#HOW TO OPEN A DWG FILE IN AUTODESK INVENTOR SOFTWARE#

Main software associated with step file by default: CATIA.

Click on the link to get more information about listed programs for open step file action. Programs supporting the exension step on the main platforms Windows, Mac, Linux or mobile. For example, to import a 3rd party assembly file as a part, you must first create or have a part file open, and then import the 3rd party assembly file into the part file. Software that open step file - ISO-10303 STEP product data file. When you import a file, Inventor automatically detects whether the imported file is a part or assembly and creates the new document accordingly. Get Started tab Launch panel Import CAD Formats.You can also place part and assembly files as components into new or existing Inventor assemblies.įor a list of supported file types, refer Translator Support. You can open or import part and assembly files from other CAD systems. Import current versions of 3rd party files.
